目录编号
Catalog
No. |
额定电流
Ampere
Rating |
额定电压
Voltage
Rating |
熔化热能I2T
Melting Integral
(A2.S) |
|
2D0100A/B |
100mA |
250V/125V |
0.001 |
|
2D0125A/B |
125mA |
250V/125V |
0.002 |
|
2D0160A/B |
160mA |
250V/125V |
0.003 |
|
2D0200A/B |
200mA |
250V/125V |
0.006 |
|
2D0250A/B |
250mA |
250V/125V |
0.012 |
|
2D0300A/B |
300mA |
250V/125V |
0.016 |
|
2D0315A/B |
315mA |
250V/125V |
0.019 |
|
2D0350A/B |
350mA |
250V/125V |
0.022 |
|
2D0400A/B |
400mA |
250V/125V |
0.035 |
|
2D0500A/B |
500mA |
250V/125V |
0.047 |
|
2D0630A/B |
630mA |
250V/125V |
0.056 |
|
2D0750A/B |
750mA |
250V/125V |
0.078 |
|
2D0800A/B |
800mA |
250V/125V |
0.098 |
|
2D1100A/B |
1A |
250V/125V |
0.3 |
|
2D1125A/B |
1.25A |
250V/125V |
0.5 |
|
2D1150A/B |
1.5A |
250V/125V |
0.6 |
|
2D1160A/B |
1.6A |
250V/125V |
0.8 |
|
2D1200A/B |
2A |
250V/125V |
1.2 |
|
2D1250A/B |
2.5A |
250V/125V |
2 |
|
2D1300A/B |
3A |
250V/125V |
2.5 |
|
2D1315A/B |
3.15A |
250V/125V |
2.9 |
|
2D1350A/B |
3.5A |
250V/125V |
3.1 |
|
2D1400A/B |
4A |
250V/125V |
4.2 |
|
2D1500A/B |
5A |
250V/125V |
7.2 |
|
2D1630A/B |
6.3A |
250V/125V |
12 |
|
额定电流的%
% of Ampere Rating |
熔断时间
Opening Time |
|
100% |
|
4 hours (大于4小时） |
|
|
200% |
|
60 sec Max (小于60秒) |
| |
|
